Manufacturer:MSI

Product Name:MSI X470 Gaming Plus Max (Socket AM4/X470/DDR4/S-ATA 600/ATX)

Model Number:X470 GAMING PLUS MAX

BIOS:
1 x 256 Mb flash
UEFI AMI BIOS
ACPI 6.1, SM BIOS 2.8
Multi-language
Chipset:AMD X470
CPU Interface:Socket AM4
CPU Support:https://www.msi.com/Motherboard/support/X470-GAMING-PLUS-MAX#support-cpu
RAM Technology:DDR4 (Dual Channel)
RAM Slots:4 x 288-pin
RAM Speeds:
DDR4 1866
DDR4 2133
DDR4 2400
DDR4 2667
DDR4 2800 (O.C.)
DDR4 2933 (O.C.)
DDR4 3000 (O.C.)
DDR4 3066 (O.C.)
DDR4 3200 (O.C.)
DDR4 3466 (O.C.)
DDR4 3733 (O.C.)
DDR4 3866 (O.C.)
DDR4 4000 (O.C.)
DDR4 4133 (O.C.)
Max. Memory Support:64GB
PCI Express 2.0 x16:1
PCI Express 3.0 x16:2
PCI Express 2.0 x1:3
S-ATA III Port(s):6
RAID:Raid 0/1/10
M.2 Socket(s):2
LAN Speed:10/100/1000
On-Board LAN:Realtek 8111H
On-Board Audio:7.1-Channel High Definition Audio
On-Board Video:AMD processor with integrated graphics is required
Back PS/2 Keyboard/Mouse Port:1
Back USB 2.0 Port(s):2
Back USB 3.2 Port(s) Type-A Gen 1:4
Back USB 3.2 Port(s) Type-A Gen 2:2
Back DVI-D Port(s):1
Back HDMI Port(s):1
Back LAN Port(s):1
Back Audio Jack(s):5
Back S/PDIF Output Port(s):1
24-pin ATX Power:1
8-pin ATX Power:1
4-pin ATX Power:1
USB 2.0 Header(s):2
USB 3.1 Header(s) Gen 1:2
Parallel Port Header(s):1
COM Port Header(s):1
Front Panel Audio Connector:1
TPM Header(s):1
Internal Other Port(s):2x 5050 RGB LED strip 12V connectors
Internal Button(s):1 x Clear CMOS
Form Factor:Standard ATX
Product Width:244mm
Product Length:305mm
Package Width:27cm
Package Length:34.5cm
Package Height:6.5cm
Gross Weight:1.50Kg
Special Features:
Supports 1st, 2nd and 3rd Gen AMD Ryzen / Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics / Athlon with Radeon Vega Graphics Desktop Processors for Socket AM4.
Supports DDR4 Memory, up to 4133(OC) MHz.
Lightning Fast Game experience: TURBO M.2, AMD StoreMI Technology, AMD Turbo USB 3.2 Gen2.
Core Boost: With premium layout and optimized power design to support more cores and provide better performance.
Mystic Light and Mystic Light Sync: 7 colours / 7 effects in one click. Synchronize other RGB solutions for customization.
Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience.
MULTI-GPU: With STEEL ARMOR PCI-E slots. Supports 3-Way AMD Crossfire.
Package Contents:
Motherboard
Support Disk
User Guide
IO Shield
2 x SATA Data cables
2 x M.2 Screws
Case Badge
SATA Cable Labels
